MODEL 811RC BATTERY CHARGER - RECONDITIONER

Coastel introduces
“Smart Battery Charger Technology”




FEATURES

  • Rapid Charging – Eliminates the need for extra Battery Packs
  • Full Battery Charge on Demand
  • Recalibration Mode – Reconditioning Extends Battery Life
  • Intelligent Charging Protects against Overcharging
  • Eliminates Crystalline Memory
  • Reconditions Batteries which have already Developed Memory
  • Keeps Battery Pack Factory Fresh and Ready to Use

GENERAL INFORMATION:

The fast charge rate is 1000mA. It will take about 1 ˝ hours to charge a fully deleted Battery Pack (time may vary)

During a Reconditioning cycle, the Battery Pack is discharged before it is charged. The discharge rate is approximately 400mA. It can take up to 6 hours to complete a Recondition Cycle.

SPECIFICATIONS

Fast Charge, 107 min. (may vary)
Discharge/Recondition, 178 min (may vary)

DIMENSIONS

Charging Station, 6.89" x 4.89" x 2.30", wt. 14oz.
175mm . x 124mm x.58mm, wt. 397g

Power Supply 6.63" x 3.50" x 1.50" wt. 14oz.
168mm x 89mm x 38mm, wt. 397g

Power Cord, 6.50" x 3.00" x 3.00" , wt. 7oz.
165mm x 76mm x 76mm wt. 198g

Fast Charge Current: 1000mA

Battery Pack, 6-1.2V Ni-Cad sub C @1500mAh

ADDITIONAL INFORMATION

Click here for Important Information on the 700 Series Port-a-Strip

click here for Product PDF files
